Lp6 Pro Led Auxiliary Light Pod - Baja Designs

Baja Designs LP6 Pro LED Auxiliary Light Pod

The LP6 Pro is a 6-inch powerhouse featuring a total of 11,225 total lumens and of 200-degree spread of usable LED light thanks to the dedicated peripheral lighting of our patented Integrated Peripheral Technology (IPT). To keep your light performing at its highest potential, the LP6 integrates our proprietary Direct Ducted Cooling (DDC) technology. This feature allows air to travel through the front of the housing, over the rear heat sinks – drastically improving cooling capacity and performance. With an colored daytime running light, low power, and high-power mode, the LP6 easily fulfills all your lighting needs.

The LP6 Pro is available in multiple patterns to suit your needs. The Driving/Combo pattern provide maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Driving (42 degrees) and spot (8 degrees) optics to provide you with a smooth blend of light for both near-field applications and distance (Lighting Zones, 1,2, 3). The Spot pattern is a longer and narrower 8-degree beam focus for illumination further down the trail or road (Lighting Zone 4 & 5) and is designed to be used in conjunction with additional wide cornering and/or driving/combo auxiliary lights.

The addition of red, blue, or green backlight options alongside our original amber on the LP6 Pro gives enthusiasts the choice to customize their vehicle for shows, photo shoots or anywhere they want to bring attention.

Features

• Satisfaction Guarantee – 30-Day Money Back Guarantee
• Limited Lifetime Warranty – Complete Purchase Protection
• uService – Replaceable Lenses And Optics
• ClearView – All The Light, Right Where You Need It
• MoistureBlock – Waterproof, Rain Proof, Submersible
• CopperDrive – Only LED Driven At 100 Percent
• 5000K Daylight – Less Driver Fatigue, Natural Color

Specs

SKU: 270001

Dimensions

• Depth (in.) 3.200
• Height (in.) 6.500
• Length (in.) 6.500
• Weight (lbs.) 4.200

Specifications

• Amperage Rating (A) 7.500
• Average Rated Life (hr.) 49,930
• Backlight Amperage Rating (A) 0.300
• Backlight Wattage (W) 4.140
• Beam Pattern Spot
• Bezel Material Billet Machined Aluminum
• Brightness (Lumens) 11225
• Description Spot; Clear
• Housing Color Black
• Housing Material Hard Anodized Machined Aluminum
• Lens Color Clear
• Lens Material Hardcoated Polycarbonate
• Light Quantity 1
• Lighting Modes High Beam/Low Beam/Day-Time Running Backlighting
• Lighting Quantity 6
• Lighting Technology LED
• Lighting Type Forward Projecting
• Mounting Hardware Included Yes
• Mounting Hardware Material Stainless Steel
• Overvoltage Protection Built-In
• Product Type LP6 Pro LED Light Pod
• Secondary Amperage Rating (A) 1.000
• Secondary Brightness (Lumens) 1972
• Secondary Light Quantity 4 LEDs
• Secondary Lighting Technology LED
• Secondary Lighting Type Integrated Peripheral Technology (IPT)
• Secondary Wattage (W) 15
• Terminal Connector DT06-4S Deutsch
• Terminal Type Mating Connector
• Universal or Specific Universal
• Wattage (W) 103.500
• Wiring Harness Included No

Standards & Compliance

• Standards/Compliance (Durability) Exceeds MIL-STD810G (Mil-Spec Testing)
• Standards/Compliance (Impact Resistance) IK10 Compliant (Mechanical Impact Testing)
• Standards/Compliance (Water Resistance) IP69K (Waterproof up to 9ft & Pressure Washable)

Notes

• This light does not come with a wiring harness. The applicable wiring harness to this light is 640172
