Kawasaki Teryx/Mule/Ridge/KRX Motorsports Camera Kit with PMX Compatibility - Rockford Fosgate

The MX-CAM is a universal camera, purpose-built for motorsports applications, making it a perfect add-on for Stage-5 and Stage-6 Color Optix kits. The high-resolution color camera provides a crystal-clear picture for backing-up or rock-crawling. When paired with a vehicle specific installation kit, the T-harness allows for easy, error proof connections along with mounting brackets. Harness plugs directly into PMX-3 and PMX-8 source units with an included trigger wire adaptor. Camera requires corresponding vehicle specific mounting kit. Details available under Accessories tab.

Designed for the off-road and for use in Rockford Fosgate Stage-5 and Stage-6 Color Optix kits, the MX-CAM is a universal camera purpose-built for motorsports applications. It is equipped with several Element Ready technologies that resist UV rays, water, dust, and corrosion. Its durable design also makes it resistant to vibration and thermal shock where true outdoor resilience is a must. Corresponding mounting kits with a simple plug-and-play interface for easy, error proof connection. Designed for use with PMX-3 and PMX-8 source units, and compatible with any source unit featuring a composite video input.

Motorsports Camera Kit with PMX Compatibility Features:

• HD Video Resolution for crystal clear image
• Element Ready design protects against outdoor exposure
• Image display switchable from mirror to normal to accommodate rear or front installation
• 1 Year Warranty

Specifications:

• Image Sensor 1/4" CMOS
• Resolution 680 x 488
• Lens 120(H), 89(V)
• Video Output 1.0Vpp Composite, 75-Ohms
• S/N Ratio > 42dB
• Minimum Illumination 0.1 Lux
• Mirror Image
• OFF = cut mirror option wire
• ON = connect mirror option wire
• Cutout Diameter 19mm (0.75")
• Operating Temp -30 to +70 Celcius
• DC Power 12V, 70mA
• Operating Voltage DC 12V (8V-15V)

Includes:

• (1) Eyeball camera with 11" pigtail

These products are protected against Dust, UV, Temperature, Water, Corrosion & Vibration.
